VITA2000:CMOS Image Sensor, Global Shutter, 2.3 Megapixel
The VITA 2000 is a 2/3 inch Widescreen Ultra eXtended Graphics Array (WUXGA) CMOS image sensor configurable in HD format (1920 x 1080) or 4:3 format (1600 X 1200). The high sensitivity 4.8 µm x 4.8 µm pixels support pipelined and triggered global shutter readout modes and can also be operated in a low noise rolling shutter mode. In rolling shutter mode, the sensor supports correlated double sampling readout, reducing noise and increasing the dynamic range.
技术特性
- True family concept
- Multiple shutter modes
- High Configurability
- Fast adaptability
- Multiple windowing
- High dynamic range
应用
- Machine Vision
- Motion monitoring
|
封装图 MARKING DIAGRAM
|
订购信息 Ordering Information
| 产品 |
状况 |
Compliance |
具体说明 |
封装 |
MSL* |
容器 |
预算价格 (1千个数量的单价） |
| 类型 |
外形 |
类型 |
数量 |
| NOIV1SE2000A-QDC |
Active |
|
CMOS Image Sensor, Global Shutter, 2.3 Megapixel, 92 FPS, LVDS Interface, Color, Micro Lens |
LCC-52 |
115AP |
3 |
Tray JEDEC |
60 |
|
| NOIV1SN2000A-QDC |
Active |
|
CMOS Image Sensor, Global Shutter, 2.3 Megapixel, 92 FPS, LVDS Interface, Mono, Micro Lens |
LCC-52 |
115AP |
3 |
Tray JEDEC |
60 |
|
| NOIV2SE2000A-QDC |
Active |
|
CMOS Image Sensor, Global Shutter, 2.3 Megapixel, 23 FPS, CMOS Interface, Color, Micro Lens |
LCC-52 |
115AP |
3 |
Tray JEDEC |
60 |
|
| NOIV2SN2000A-QDC |
Active |
|
CMOS Image Sensor, Global Shutter, 2.3 Megapixel, 23 FPS, CMOS Interface, Mono, Micro Lens |
LCC-52 |
115AP |
3 |
Tray JEDEC |
60 |
|
