STiH251 Advanced STB decoder with integrated DVB-T/DVB-T2/DVB-C demodulator
The STiH251 uses state-of-the-art process technology to provide a fully featured HD AVC, DVB-T2 and DVB-T demodulator/decoder IC.
It is a highly integrated system-on-chip, suitable for STB markets acrossterrestrial, and terrestrial/IP hybrid networks worldwide.
技术特性
- Integrated DVB-T2 and DVB-T demodulator
- Compatible with low to high IF tuners
- ADC for RF signal strength indicator
- Advanced high-definition video decoding (H264/VC-1/MPEG2)
- Advanced standard-definition video decoding (H264/VC-1/MPEG2/AVS)
- Advanced multi-channel audio decoding (MPEG 1, 2, MP3, DD/DD+, AAC/AAC+, WMA9/WMA9Pro)
- Linux, Windows CE and OS21 compatible applications CPU
- 32-bit DDR1/DDR2 compatible local memory interface
- Multi-stream, DVR capable transport stream processing
- Extensive connectivity (dual USB hosts, e-SATA, Ethernet MAC/MII/RMII and PCI)
- Advanced security and DRM support including SVP, MS-DRM and DTCP-IP
| 功能框图
 |
STiH251 订购信息
| 订购型号 |
产品状态 |
美金价格 |
数量 |
封装 |
包装形式 |
温度范围 |
材料声明 |
| STiH251ZUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251ZUD |
| STiH251ZHD |
Preview |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251ZHD |
| STiH251-HUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-HUD |
| STiH251-GUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-GUD |
| STiH251-DUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-DUD |
| STiH251BRUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251BRUD |
| STiH251-OUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-OUD |
| STiH251BFUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251BFUD |
| STiH251-1UD |
Preview |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-1UD |
| STiH251BSUD |
Preview |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251BSUD |
| STiH251-SUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-SUD |
| STiH251BLUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251BLUD |
| STiH251-MUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-MUD |
| STiH251-CUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-CUD |
| STiH251-KUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-KUD |
| STiH251-EUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-EUD |
| STiH251-UUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-UUD |
| STiH251-NUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-NUD |
| STiH251BVUD |
Preview |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251BVUD |
| STiH251-BUD |
Active |
|
|
FPBGA700 27x27x2.19 |
Tray |
|
STiH251-BUD |
DATA BRIEF
| 描述 |
版本 |
大小 |
| STiH251 : DB1207: Advanced STB decoder with integrated DVB-T2 and DVB-T demodulator |
2 |
74KB |
FLYERS
| 描述 |
版本 |
大小 |
| STiH251 HD and SD decoder for DVB-T2 markets |
1.0.0 |
304KB |
